The selection of the main structure material for the clean room is centered around achieving a balance among cleanliness, load-bearing capacity, corrosion resistance, cost, and ease of installation. The mainstream frameworks include aluminum profiles, stainless steel square tubes, and powder-coated iron square tubes. The enclosures commonly use anti-static PVC curtains, acrylic/PC panels, tempered glass, and color steel plates. 1. Frame Material (Core Load-bearing Structure) 1. Aluminum Profiles (Most Commonly Used) Applicable scenarios: Medium-low cleanliness (ISO 7–8 levels), small and medium-sized, temporary / mobile clean rooms, general areas of electronics / semiconductors. Advantages: Lightweight, quick installation, can be assembled by one person, no heavy equipment required. Surface is anodized, smooth, dust-free, easy to clean, and not prone to dust accumulation. Modular, reusable for disassembly, highly expandable. Disadvantages: Limited load-bearing capacity, not suitable for hanging heavy FFU / equipment. Weak impact resistance, prone to oxidation and discoloration in humid / acid-base environments over long-term use. Selection tips: Prefer 40×40/40×80 industrial purification aluminum profiles, with anodized surface and anti-static treatment. 2. Stainless steel square tubes (304/316, preferred for high-end applications) Application scenarios: High cleanliness (ISO 5–6 levels), pharmaceutical / biopharmaceutical / GMP, food, humid / acid-base corrosive environments. Advantages: 304 Resistant to daily

Wind shower transfer window high-efficiency filter – Standard installation steps I. Pre-installation preparations Stop the machine, disconnect the power supply, and hang the “Equipment maintenance, do not close the switch” sign. Tools needed: Cross-head screwdriver, clean cloth, gloves. Clean the top/back of the transfer window’s fan compartment, wipe off dust. Check the new high-efficiency filter: No damage, no deformation, no moisture or mold Frame is intact, sealant strips are complete The shell has an air flow direction arrow II. Disassembly of the old high-efficiency filter Open the filter maintenance cover (usually on the top or back of the transfer window). Loosen the tightening bolts / clasps, slowly remove the old filter. Clean the installation slot and the interior of the air duct again, without dust or debris. III. Installation of the new high-efficiency filter (key steps) Confirm the direction The air flow arrow on the filter → towards the wind shower chamber and nozzle direction. Place the filter smoothly in the installation slot Hold the frame with both hands, do not touch the filter paper Place it gently in position, without twisting or squeezing Complete the sealing around it Ensure that the sealant strips are fully adhered, without warping or

I. Most Accurate: Check the differential pressure gauge (recommended) Primary filter Normal differential pressure: < 50 Pa Replacement required: ≥ 100 Pa or double the initial value Intermediate filter Normal differential pressure: < 100 Pa Replacement required: ≥ 200 Pa High-efficiency filter (HEPA) Normal differential pressure: < 150 Pa Replacement required: ≥ 300 Pa or significant decrease in air volume II. Most Intuitive: Check the appearance If any of the following conditions are met, it is time to replace the filter: The filter is blackened, yellowed, or heavily clogged with dust The filter paper is damaged, leaking, or deformed The frame seal is detached or cracked The surface has mold spots, is damp, or has water stains III. Most Practical: Check the operating effect When these situations occur, it is basically a clogged filter: The air supply volume of the equipment decreases, and the blowing sensation weakens The air outlet is not uniform or even blocked The door body or box leaks air, makes a whistling sound The pressure difference in the clean area cannot be maintained IV. Mandatory Replacement by Time (Backup Plan) Primary filter: 3 to 6 months Intermediate filter: 6 to 12 months High-efficiency filter: 1 to

Constant-flow air supply ceiling – Core component replacement cycle 1. High-efficiency filters HEPA/ULPA (the most critical consumable) Classical cleanroom / operating room: 1-2 years High usage frequency, large amount of dust: 6-12 months Judgment criteria: Resistance reaches twice the initial resistance or cleanliness does not meet standards → must be replaced 2. Diffusing membranes / diffusers / damping nets PTFE diffusing membranes: 2-3 years Aluminum alloy diffusers: 3-5 years If deformed, clogged, or the effect significantly decreases after cleaning, replace 3. Fans, motors Ordinary centrifugal fans: 5-8 years DC brushless fans: 8-10 years If noise increases, air volume significantly decreases, or abnormal heating → replacement 4. Sealing parts, liquid tank sealant Sealing strips: 1-2 years Liquid tank sealant: 3-5 years If aging, cracking, or air leakage occurs → replace immediately 5. Pressure boxes, frames, shells These belong to structural components and do not need to be replaced regularly Normal use can last 10-15 years with the ceiling One-sentence summary (for your convenience) Filters: must be replaced within 1 year Diffusing membranes: 2-3 years Fans: 5-8 years Sealing parts: 1-2 years

The main structure of the air supply ceiling ( laminar flow air supply ceiling ) typically has a lifespan of 15–20 years, and the core filter components need to be replaced every 1–2 years; daily maintenance mainly involves pressure difference monitoring, filter management, and inspection of seals and structure, ensuring cleanliness and stable airflow. I. Service Life (Standard Operating Conditions) 1. Main Structure (static pressure box, frame, equalizing plate) Design life: 15–20 years (high-quality hot-dip galvanized / stainless steel material) Influencing factors: Material: 304/316 stainless steel > hot-dip galvanized steel > ordinary steel Environment: Humidity, corrosive gases, high dust can shorten the lifespan Maintenance: Regular cleaning, anti-corrosion, and sealing maintenance can extend the lifespan 2. Core Filter Components (filters) Primary efficiency (G4): 3–6 months replacement / cleaning Intermediate efficiency (F8): 6–12 months replacement High efficiency / ultra-high efficiency (H13–U15): 1–2 years replacement (or when the final resistance reaches twice the initial resistance) 3. Seals and Wearable Parts Sealant strips / silicone: 2–3 years replacement Equalizing membrane (PTFE): 5–8 years (with a temperature resistance of 121°C, sterilizable) II. Daily Maintenance (Hierarchical Execution) 1. Daily / Shift (Basic Inspection) Visual inspection: No abnormal noise, vibration, uneven air supply, dust accumulation on the

Conclusion: You can replace it yourself, but there are certain conditions – it’s not just a simple replacement. It must meet the requirements of compliance, sealing, leak detection, and verification. Otherwise, the replacement would be in vain and could even affect the cleanliness level. 1. When can you replace it yourself? If the following conditions are met, you can replace it yourself: You have personnel who understand equipment maintenance (electricians / equipment technicians are sufficient) You have filters of the same specification, size, and qualified (with certificates and test reports) After replacement, simple verification of air velocity, leak detection, and cleanliness can be done The workshop / laboratory does not involve GMP, pharmaceutical, etc. high-level certification (or it is internally allowed to replace by yourself) 2. Key steps for self-replacement (simplified version) Turn off the power, unplug the power supply Remove the decorative cover, trim, and old high-efficiency filter Clean the box, sealing groove, and replace the sealing rubber strip (aging requires replacement) The new high-efficiency filter should have the arrow pointing towards the outlet direction and be evenly pressed Loosen the screws diagonally and tighten them to ensure no air leakage Turn on the machine to measure air velocity,

To determine whether an HEPA filter needs to be replaced, it’s quite simple. I’ll present you with a straightforward method that can be applied directly on-site without the need for complex instruments. Line workers will understand it easily. 1. The most intuitive and quickest method (without instruments) – The wind speed has significantly decreased – Turn on the fan and place your hand at the outlet. You’ll feel very weak and soft wind – Before it was strong, but now it’s noticeably weaker → It’s likely clogged – The dust in the operation area has increased – More dust is falling on the tabletop and samples – The colony count and contamination rate have risen → First suspect that the HEPA filter has failed – The usage time has exceeded the limit – In a regular laboratory: ≥ 2 years – In a workshop with excessive dust and poor environmental conditions: ≥ 1 year requires a focused check – The primary filter is already very clean, but the wind speed is still low – The primary filter has been washed or replaced, but the wind speed still cannot increase → The blockage is in the HEPA filter, not the primary

Nozzle blockage in the air shower: Troubleshooting steps + Solution 1. Determine if the nozzle is blocked Any of the following conditions indicates a nozzle blockage: Some nozzles have very little or no airflow, while others are normal The airflow is uneven, skewed, or intermittent The noise in the air shower increases, and the airflow becomes significantly weaker The filter was just replaced, but the airflow still cannot be increased 2. Safety prerequisite (must be done first) Turn off the power supply of the air shower Turn off the fan Open the door to allow the equipment to completely stop running 3. Steps for nozzle blockage handling (standard procedure) 1. Locate the blocked nozzle Examine one by one: No airflow, weak airflow, skewed airflow indicates a blockage Pay special attention to the top, corners, and inner side nozzles, where dust is most likely to accumulate 2. Remove the nozzle (most are screw-type) Hold the nozzle and rotate counterclockwise to remove it Do not use brute force to pry, to avoid damaging the base 3. Clean the blockage The most effective and commonly used three methods are: Air compression blowing (recommended) Blow from the air intake side to the air exhaust

The main causes of nozzle blockage in the air shower room 1. Failure of the front-end filter (the most common) The primary filter is not cleaned or replaced for a long time, and dust and debris directly enter the air duct The high-efficiency filter is damaged or leaks, and small particles penetrate and enter the nozzle The filter installation is not tight, and there is bypass leakage, with dust taking the shortcut 2. Dust brought in by the environment and materials (source problem) The goods / packaging carry a large amount of fibers, paper debris, dust, and hairs into the air shower The workshop has a lot of dust and the environment is dirty, making the air shower a “dust collector” The materials have powder, debris, plastic fringes, which are blown into the nozzle by the wind 3. Accumulated dust and debris inside the air duct The air duct and static pressure box of the air shower room have not been cleaned for a long time, and the accumulated dust is blown into the nozzle The insulation cotton and sealant in the air duct age and fall off, leaving debris that blocks the nozzle The fan impeller accumulates large pieces

High-temperature with partitioned air filter (mostly of high-efficiency / ultra-high-efficiency level, with a temperature resistance range of 250–350℃), mainly used in high-temperature working conditions and high-cleanliness air purification scenarios. Here are its main application areas: 1. Electronics and semiconductor manufacturing Core scenarios: High-temperature clean ovens, diffusion furnaces, annealing furnaces, and high-temperature purification workshops for processes such as wafer manufacturing, chip packaging, lithography, etching, and thin film deposition. Function: In high-temperature processing environments, continuously filter particles of 0.3μm and above to ensure the cleanliness of wafer surfaces and prevent dust from causing product defects. 2. Biomedicine and pharmaceuticals Core scenarios: Aseptic preparation workshops, injection / infusion production lines, biosafety cabinets, clean tunnels, high-temperature sterilization ovens, freeze-dryers. Function: Meet GMP/A-level cleanliness requirements, provide sterile and dust-free air during high-temperature drying and sterilization processes, and prevent microbial and particle contamination. 3. Automotive and industrial painting Core scenarios: Automotive body / component painting lines, high-temperature baking ovens, drying furnaces, curing furnaces. Function: Filter high-temperature hot air, intercept paint mist and dust, ensure the smoothness and adhesion of the paint surface, and improve the painting quality. 4. Food and beverage processing Core scenarios: Aseptic packaging workshops, high-temperature sterilization tunnels, baking / roasting production lines, clean

The service life of the high-temperature air filter with a partition plate is not fixed. The core factors depend on the operating temperature, dust load, maintenance level, and industry standards. The industry standard range is 1 to 5 years. In extreme conditions, it can be as short as several months, while in high-quality conditions, it can reach 8 to 10 years. I. Industry Standard Life Reference (Continuous Operation) Conventional high-temperature conditions (200–250℃, good cleanliness) Electronics / Semiconductors, pharmaceutical dry heat sterilization, coating drying: 1.5–3 years Food baking / aseptic packaging, laboratory high-temperature ovens: 2–4 years Severe high-temperature conditions (250–350℃, high dust / high humidity / chemical corrosion) Chemical high-temperature reactions, catalyst regeneration, waste incineration pre-treatment: 6–18 months Semiconductor diffusion furnaces, photovoltaic / lithium battery high-temperature sintering: 1–2 years Ultra-high temperature / special conditions (above 350℃, stainless steel / ceramic partitions) Special material sintering, aircraft engine testing, nuclear emergency ventilation: 5–10 years + II. Key Factors Affecting Life Temperature and Thermal Cycling The higher the temperature and the more frequent the thermal shock, the faster the filter material / seal aging, and the shorter the service life. Continuous operation at 250℃ is 30%–50% longer than frequent start-stop and cold-hot alternation. Dust

The core of daily maintenance for ultra-low resistance high-efficiency filtration units is pressure difference monitoring, regular inspections, standardized cleaning / replacement, and seal checks to ensure low resistance and high efficiency, extend lifespan, and avoid air leakage and secondary pollution. 1. Daily Monitoring (daily / per shift) Pressure difference monitoring: Record the pressure difference at the inlet and outlet, establish an initial baseline value; the final resistance is usually 1.5–2 times the initial value, and an alert is triggered when it reaches 80%. Appearance and operation: Check for deformation, damage, and dust accumulation on the casing and frame; no blockage at the inlet and outlet; the fan / valve operates smoothly, without abnormal sounds, and no abnormal vibrations. Air volume and cleanliness: Observe if the supply air volume is stable; whether the particle concentration in the clean room / workshop meets the standard. Record and archive: Daily record the pressure difference, operating status, and abnormal situations, forming an operation log. 2. Periodic Inspection and Maintenance (according to schedule) 1. Every week / every two weeks Clean the casing and floating dust on the inlet surface (using a soft brush / vacuum cleaner, gently sweep from the clean side to the
