Large adsorption area, strong adsorption performance, high activated carbon content, good ventilation performance, low resistance, long life and low cost Effective adsorption of industrial waste gas
|
Product material |
Performance and graph |
|
Filter material: |
activated carbon non-woven fabric, activated carbon particles |
|
Outer frame: |
aluminum frame, stainless steel, galvanized frame |
|
Maximum temperature: |
≤70℃ |
|
Maximum humidity: |
≤95%RH |
Chemical filters selectively adsorb gaseous pollutant molecules, unlike dust removal filters that mechanically intercept impurities. Adsorption is the adsorption phenomenon of gas or liquid molecules on the surface of solid substances, in which solid substances are called adsorbents and adsorbed substances are called adsorbates. Adsorption can be divided into physical adsorption and chemical adsorption. Physical adsorption mainly relies on van der Waals forces, often at lower temperatures, and the process is reversible. For some gases (such as ammonia and hydrogen sulfide), the adsorption capacity of ordinary activated carbon is limited. At this time, people often chemically treat them to enhance their ability to remove specific pollutants. The adsorption of chemically treated adsorbent materials and harmful gases is called chemical adsorption, and the process is irreversible. The adsorption process can be divided into three stages: gas molecules diffuse to the outer surface of activated carbon, referred to as external diffusion; gas molecules diffuse to the inner surface in the micropores of activated carbon, referred to as internal diffusion; gas molecules are adsorbed on the inner surface of activated carbon.
1. Purification of new air before introduction into the air circuit.
2. Economical, long-lasting, solution to many odor problems.
3. Easy to install.
4. It is made of high quality activated carbon media.
5.Large air flow, low resistance,and long service life.
6.Good effect on odor removal
It is mainly composed of filter material, outer frame and activated carbon. The filter material can be made of activated carbon non-woven fabric, activated carbon particles and other materials, which have the advantages of large adsorption area, strong adsorption performance, high activated carbon content, good ventilation performance, low resistance, long life and low cost. The outer frame is generally made of aluminum frame, stainless steel frame, galvanized frame and other materials, which are corrosion-resistant, high-strength, easy to process and can meet the use requirements of different occasions.
